Bimini Top
Overview
autobimini
autobimini is a fully automatic 4-bow bimini top that can be added to virtually any pontoon or deck boat. At the touch of a button, autobimini electrically extends for full shade coverage, adjusts to different positions to block the sun and then easily retracts to stow away within a boot. There are two versions of autobimini.
autobimini uses intelligent motion control with motor feedback for closed loop bimini operation. autobimini has a host of features and more gentle on the mechanics of the bimini system. Since autobimini is smart, it can start and stop in any position and features our patented actuator, controller, and electronic synchronization technology. (US Patent 11,498,646 B1)

autobimini lite
autobimini lite uses a helm mounted momentary switch to raise or lower the bimini and automatically stop at the UP, DOWN or RADAR hard stop positions. autobimini lite incorporates a heavy duty reversing contactor operated by the helm mounted switch. The reversing contactor delivers power to both actuators to simultaneously drive them to the hard stop positions. Once at the hard stop position, a built-in circuit breaker automatically stops both actuators. The circuit breaker will automatically reset after a few seconds.
Enjoy 30% more coverage than standard bimini tops with our generous 10’ length and widths that adjust to fit pontoon and deck boats between 92” to 102” wide.




Key Features





AUTOBIMINI KEY
Features
Intelligent motion controller
Dual axis electronic synchronization, Remote FOB, Smartphone APP, Keypad and console switch operation
Dual smart electric actuators
Smart motors for electronic synchronization
Heavy Duty Aluminum Frame
4-Bow Design
1.25” x 0.125” Square Tubing
Adjustable width from 92” to 102”
12VDC Battery Power
Premium Coverage
Generous 10 foot coverage
with matching storage boot
Marine Grade Construction
Built tough for marine environments

All Features
Feature | autobimini | autobimini lite |
---|---|---|
Multi-Axis Motion Controller | ✅ | |
Electronic Synchronization | ✅ | |
Auto Stop | ✅ | |
Soft Stop | ✅ | |
Bluetooth | ✅ | |
Sleep Mode | ✅ | |
Manual Override Mode | ✅ | |
REGEN Mode | ✅ | |
Remote FOB | ✅ | |
Smart Phone APP |
✅ Real Time Diagnostics |
|
Waterproof Enclosure | ✅ |
|
Keypad w/Status LED’s | ✅ |
|
Dual Electronic Actuators |
✅ Smart |
✅ |
Heavy Duty Aluminum Frame | ✅ |
✅ |
4-Bow Design | ✅ |
✅ |
1.25” x 0.125” Square Tubing | ✅ |
✅ |
Positioning | Any position |
UP, DOWN, RADAR |
Marine Grade Canopy |
✅ 7 colors |
✅ 7 colors |
Matching Storage Boot | ✅ |
✅ |
12VDC Battery Power | ✅ |
✅ |
Electronic Circuit Breaker |
✅ 20A |
✅ 8A |
Helm Mounted Switch | Optional with LED | ✅ |
LED Canopy Light | Optional remote controlled | |
12VDC Reversing Contactor | ✅ | |
Speed Limits (Boat & Wind) | ||
UP Position | 25MPH | 25MPH |
UP w/support arms | Standard 45MPH |
Standard 35MPH |
RADAR (w/boot) | 50MPH | 50MPH |
Towing (DOWN w/boot) | 70MPH | 70MPH |
All Features
Feature
autobimini
autobimini lite
Multi-Axis Motion Controller
✅
Electronic Synchronization
✅
Auto Stop
✅
Soft Stop
✅
Bluetooth
✅
Sleep Mode
✅
Manual Override Mode
✅
REGEN Mode
✅
✅
✅
Real Time Diagnostics
✅
✅
✅
Smart
✅
Heavy Duty Aluminum Frame
✅
✅
4-Bow Design
✅
✅
1.25” x 0.125” Square Tubing
✅
✅
✅
7 colors
✅
7 colors
✅
✅
✅
✅
✅
20A
✅
8A
Helm Mounted Switch
Optional with LED
✅
Optional remote controlled
✅
Speed Limits (Boat & Wind)
UP Position
25MPH
25MPH
UP w/support arms
Standard
45MPH
Standard
35MPH
RADAR (w/boot)
50MPH
50MPH
Towing (DOWN w/boot)
70MPH
70MPH
autobimini
THE SMARTEST Design



















mounting hardware kit provided





autobimini lite
THE SIMPLE Design

with Console Switch


with 25 feet of marine grade cable










mounting hardware kit provided
